Spectracom SecureSync User Manual

The Edit window allows the configuration of the following settings:
Signature Control: Used to control when the IRIG modulation will be present. This function
allows the modulation to stop under certain conditions;see also "Signature Control" on
page141.
Format: Used to configure the desired IRIG output formatting. The available choices are:
IRIG A
IRIG B
IRIG G
IRIG E
NASA-36
Modulation: Changes the type of output signal modulation. The available choices are:
IRIG DCLS: TTL-modulated output
IRIG AM: Amplitude-modulated output. The amplitude of the output is determined
by the value entered in the Amplitude field.
Frequency: The IRIG modulation frequency. This is determined by the configuration of
Format and Modulation Type. See "IRIG Carrier Frequencies" on page544 for details.
Coded Expression: Defines the data structure of the IRIG signal, where:
BCD = Binary Coded Decimal
TOY = Time of Year
412 SecureSync User Reference Guide
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
