Spectracom SecureSync User Manual

Provided
IRIG Code Format
Code Description
B122 IRIG B, AM, BCD
B123 IRIG B, AM, BCD, SBS
B124 IRIG B, AM, BCD
TOY
, BCD
YEAR
, CF, SBS
B125 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
, CF
B126 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
B127 IRIG B, AM, 1kHz, BCD
toy
, BCD
year
, SBS
G-DCLS
G001 IRIG G, DCLS, BCD, CF
G002 IRIG G, DCLS, BCD
G005 IRIG G, DCLS, BCD
TOY
, BCD
YEAR
, CF
G006 IRIG G, DCLS, BCD
toy
, BCD
year
G-AM
G141 IRIG G, AM, 100kHz, BCD,CF
G142 IRIG G, AM, 100kHz, BCD
G145 IRIG G, AM, 100kHz, BCD
TOY
, BCD
YEAR
, CF
G146 IRIG G, AM, 100kHz, BCD
toy
, BCD
year
Table 5-17:
Accepted IRIG input reference formats
IRIG Output: Signal State
To quickly view if an IRIG output is enabled, or disabled, navigate to the option card’s Status
Summary panel. For instructions, see: "Viewing an Input/Output Signal State" on page349.
IRIG Input: Edit Window
To configure the IRIG Input (also referred to as ‘Reference’), navigate to its Edit window. For
instructions, see: "Configuring Option Card Inputs/Outputs" on page348.
The Web UI list entries for these cards are: IRIG In/Out BNC and IRIG In/Out Fiber.
The connector number is: J1.
SecureSync User Reference Guide 419
APPENDIX

Spectracom SecureSync Specifications

General

Model	SecureSync
Time Reference	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Disciplines	GNSS, IRIG, PTP, NTP, SyncE
Inputs	GPS, GLONASS, BeiDou, Galileo, IRIG, NTP, PTP, 1PPS
Outputs	NTP, PTP, 1PPS, IRIG
Protocols	PTP, NTP, SNMP, SSH, HTTPS
Form Factor	1U Rack-mount
Redundancy	Optional redundant power supply
Security Features	Password protection, access control lists, SSH, HTTPS, SNMPv3, NTP authentication, PTP authentication
Power Supply	100-240 VAC, 50-60 Hz
Operating Temperature	0°C to +50°C
Dimensions	44.45 mm (H) x 482.6 mm (W)
