Chapter 3
TimeProvider 5000 CLI Command Set
Ethernet Port 1
ETH1 link/activity indicator
ETH1 Green - Link has been established
Flashing Green - Link activity
Off - Link has not been established
Ethernet Port 2
ETH2 port link/activity indicator
ETH2 Green - Link has been established
Flashing Green - Link activity
Off - Link has not been established
Local Oscillator State
Indicates the current mode of
operation of the LO servo
HOLD Off - Oscillator is operating in Locked mode
Amber - Oscillator is operating in Holdover or
Acquire modes
Flashing Amber - Oscillator is operating in
Warm-up mode
Table 3-3. LED Descriptions for Expansion Shelves
LED Name Color Description
PWR A Red Power A is absent
Off Power A is normal
PWR B Red Power B is absent
Off Power B is normal
ALM Red There are active alarms
Off There are no active alarms
MGMT Green Management port is connected
Blinking Green Management power has activity
Red Management is not connected
REF Green Valid reference
Amber No valid reference
Off Inputs disabled
Blinking Amber Warm up
Table 3-2. LED Descriptions for Main Shelf (Continued)
LED Label Description
