Chapter 1 Overview
TimeProvider 5000 Connections
 1.544 Mb/s (G.703)
 1.544 MHz (G.703)
These ports can also be software configured as T1 outputs .
Table 1-6 shows the pin assignments for the RJ-48C connectors for the
programmable T1 input/output ports.
10MHz & 1PPS Output Connections
Two of the four mini-BNC ports (Port3 and Port4) on the 090-50312-01 version of
the I/O module are 1PPS and 10MHz output ports. See Figure 1-5.
Port3 and Port4 on the 090-50314-01 version of the I/O module are also 1PPS and
10MHz dedicated output ports. See Figure 1-6.
Note: The T1 ports on the 090-50314-01 version of the I/O
module
can also be configured as E1 and 2048 kHz inputs or outputs
which meet the G.703 mask for impedance of 120 ohms, balanced.
Table 1-6. T1 Input/Output Port Pin-Outs - RJ48C Connector
Pin Signal
1Rx Ring
2Rx Tip
3NC
4Tx Ring
5Tx Tip
6NC
7NC
8NC
Note: Units that provide 1PPS and 10MHz outputs must be
ordered from the factory; they cannot be reconfigured in the
field. One port provides 1PPS output and one port provides
10 MHz output.
