098-00028-000 Revision F – May, 2012 TimeProvider 5000 Users Guide 507
Appendix F PTP Probe Option
Controlling the Probe With TimeMonitor PDV
Entering CLI Commands Manually with TimeMonitor PDV
The TP 5000 Probe can also be configured and operated with Command Line
Interface (CLI) commands via a telnet session over TCP/IP. In addition to the GUI,
the TimeMonitor PDV software provides two ways to manually enter CLI commands
to the TP 5000 PTP Probe. In Command mode, commands can be entered in the
Command field and sent to the TP 5000 probe by clicking the Send button.
Table F-3. Descriptions of TimeMonitor PDV Functionality
Function Description
1
Connect to TP 5000 probe.
a. Select RS-232 or TCP/IP (Disconnect mode).
First time connection to a network requires connection via RS-232 to
change IP address of MGMT port for TP 5000 Probe.
b. Login to TP 5000 Probe (Command mode).
c. Turn off Telnet firewall of TP 5000 Probe (Command mode, logged in).
2
Configure TimeMonitor and TP 5000 Probe address (Command mode).
a. Select Probe port.
b. Enter Grandmaster IP address and Probe IP address.
c. Enter Clock ID for Grandmaster.
d. Enable Probe for selected port and change Probe IP address per
entry in 2b.
3
Measure packet delay between Grandmaster and TP 5000 Probe.
a. Enter file name and title for PDV measurement data.
b. Select sync rate for measurement and lease duration.
c. Start and Stop measurement (Command mode, logged in)
4
Analyze data file (Command or Disconnect mode)
a. Set the max number of samples for measurement plot.
b. Select type of measurement plot and start analysis.
