316 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 4 Provisioning
Provisioning the Input Reference
To provision the TimeProvider 5000 for a GNSS reference in auto mode, with a
track-mode of Priority-beidou, perform the following steps:
1. Login at the Admin or Config-user level (see Logging In, on page 275).
2. Type
set ref mode time and press Enter.
3. Type
set gnss mode auto and press Enter.
4. Type
set gnss track-mode priority-beidou and press Enter.
5. Type
set gnss state enable and press Enter.
6. Type
show ref and press Enter to verify that the reference mode has been set
to Time.
Setting a 1PPS+TOD Input as Reference
Ports 1 and 2 on the 090-50315-01 version of the I/O module are 1PPS+TOD
inputs. Use the following procedure to set these ports as reference inputs and to
enable the inputs.
Example
To provision the TimeProvider 5000 for a 1PPS+TOD input reference, perform the
following steps:
1. Login at the Admin or Config-user level.
2. Type
set ref mode time and press Enter
3. Type
set pps-tod state port1 enable and press Enter.
4. Type
set pps-tod state port2 enable and press Enter.
5. Type
show ref and press Enter to verify that the reference mode has been set
to Time.
Note: Disabling the input port will clear all alarms and events related
to this port.
Note: Command “set ref mode time” has the same meaning as
“set tod-source GPS” and “set ref mode frequency” has
the same meaning as “set tod-source sys”. The
set
tod-source
command has been deprecated.
