Symmetricom TimeProvider 5000 User Manual

098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 361
Chapter 5 Operating
Determining Status
Determining Status
show alarm (displays presently active alarms)
show gps status (displays GPS information)
show inventory (displays details for IMC and IOC cards)
show status (displays general status of unit)
Forcing Unit To Send New Time in Time Reference Mode
The user may need to manually sync the IOC time and phase to the time
reference’s time and phase if there is any difference. After the reference mode is
changed to time and the system is locked to the reference, the TP5000 response
depends on whether Auto-Sync is enabled and whether the TP5000 has left
warm-up. The possible system responses are shown in Table 5-1 below.
Note: The "sync tod-source" command forces the TimeProvider 5000
to immediately start using the new reference time. The use of this
command should be carefully planned since it may cause jitter in the
1PPS output of the TimeProvider 5000.
Table 5-1. Force Unit to Send New TIme vs. Auto Sync
Condition of
TP5000
Auto-Sync
State
System Response
Unit is still in warm-up Enabled Time and phase will automatically sync to the
time reference
Unit is still in warm-up Disabled Time and phase will automatically sync to the
time reference
Unit has left warm-up Enabled Time and phase will automatically sync to the
time reference
Unit has left warm-up Disabled Alarm ID #8
(Manual sync IOC time to IMC
required
) will be generated.
Use the command “sync tod-source now” to
manually sync IOC time and phase to the time
reference and clear the alarm
