78 TimeProvider 5000 Users Guide 098-00028-000 Revision F – May, 2012
Chapter 2 Installing
Signal Connections
.
Figure 2-20. DTI and DTI/ETH Connection for TP 5000 and One Expansion Shelf
Table 2-9. Custom Cable RJ-45 Wiring Connections: UTI Port to Expansion Shelf EXP Port
UTI Port on I/O Card
Mating Connector
Pins
Signal
EXP Port on Expansion Shelf
Mating Connector
Pins
1DTI+ 7
2DTI 8
