098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 469
Appendix C Installing the GPS Antenna
Antenna Kits and Accessories
The cable between the antenna and the TimeProvider 5000 cable should be kept to
the shortest reasonable length. Before using additional cables, verify that the total
antenna system gain is acceptable as described in the Selecting the Proper Gain
Antenna section of Appendix D. The tables listed below provide information about
the antenna:
 Table C-1 lists the item number and provides a brief description of each antenna
 Table C-2 provides specification information for GPS antenna with internal LNA
 Table C-3 lists the item numbers and provides a brief description of the antenna
accessories available for the GPS series antennas.
Table C-2 provides specifications for GPS antennas with internal LNA.
Table C-1. GPS Antennas with Internal LNA
Part Number Description Minimum Cable Length
990-13091-006 26 dB Antenna with 3 m + 3 m cable 3 m (10 ft)
990-13091-013 26 dB Antenna with 3 m + 10 m cable 3 m (10 ft)
990-13073-070 40 dB Antenna with 10 m + 60 m cable 30 m (100 ft)
990-13074-150 48 dB Antenna with 10 m + 140 m cable 76 m (250 ft)
990-13075-230 48 dB Antenna with 10 m + 220 m cable and
20 dB Amplifier
198 m (650 ft)
Table C-2. Specifications for GPS Antennas with Internal LNA
Characteristic Specification
Mechanical
Mounting 4 holes, 1.75 in x 1.75 in (4.445 cm x 4.445 cm) centers,
0.25 in (0.635 cm) mounting holes
Diameter 3.5 in (88.9 mm)
Height 12.94 in (328.7 mm), including pipe mount
Weight < 3 lbs (1.4 kg)
Environmental
Temperature –40C to +75C
Relative Humidity 100% Non-Immersed
Altitude
200 ft. (60 m) below sea level to 13,000 ft. (3962 m) above sea level
Electrical
Power 4.7 to 28 VDC (5 VDC Nominal)
