098-00028-000 Revision F – May, 2012 TimeProvider 5000 Users Guide 77
Chapter 2 Installing
Signal Connections
.
.
Table 2-7. UTI Port RJ-45 Connector Pin Assignments - I/O Card
Pin Signal
Comment
1DTI+ DTI
2DTI DTI
3 No connection
4 No connection
5 No connection
6 No connection
7 No connection
8 No connection
Table 2-8. EXP Port RJ-45 Connector Pin Assignments - TP E10 & TP E30 Expansion Shelves
Pin Signal
Comment
1RX+
(Receive positive)
Ethernet (10/100Base-T)
2RX
(Receive negative)
Ethernet (10/100Base-T)
3TX+
(Transmit positive)
Ethernet (10/100Base-T)
4 Reserved
5 Reserved
6TX
(Transmit negative)
Ethernet (10/100Base-T)
7DTI+ DTI
8DTI DTI
