Appendix B Specifications and Factory Defaults
Specifications
Output Signals
TP 5000 Main Shelf Output Signal Specifications
TP 5000 Main Shelf Output Signal Specifications
Parameter Specification
PTP
Ports Ethernet Small Form-factor Pluggable (SFP)
Optical 1000 Base-X
Electrical 100/1000 Base-T
E1
Type G.703 Section 9 Framed E1
or G.703 Section 13 2048 kHz
Format CAS or CCS, CRC4 enable/disable
Impedance 75 ohms
Connector Mini-BNC or SMB coax
10 MHz
Impedance 50  unbalanced
Amplitude 1.5 dBm to 4.5 dBm
Signal type Sine
Connector Mini-BNC
Long-term Frequency Stability <0.01 ppb, when locked to PRC/GPS
Phase Noise (minimum)
 1 Hz: 60 dBc/Hz
 10 Hz: 80 dBc/Hz
 100 Hz: 100 dBc/Hz
 1 kHz: 110 dBc/Hz
 10 kHz: 140 dBc/Hz
 100 kHz: 145 dBc/Hz
1PPS
Impedance 50  unbalanced
Amplitude 2.0 Vpp
Signal type Square Wave
Rise Time < 20 ns
Connector Mini-BNC
Pulse Width 5 s ±10%
