34 TimeProvider 5000 Users Guide 098-00028-000 Revision F – May, 2012
Chapter 1 Overview
TimeProvider 5000 Connections
UTI Input and Output Connections
UTI ports are available in the 090-50311-01, 090-50312-01, and 090-50314-01 I/O
modules. The UTI ports use standard DTI pin-outs, as shown in Table 1-2.
These ports can be used to connect to expansion shelves, TimeProvider E10 or
E30, with a custom cable. This custom cable should be built with twisted-pair cable,
CAT5 or better, with RJ-45 connectors and the pinouts in Table 1-3.
Note: The 090-50315-01 I/O card has a different pin assignment and
uses a standard twisted-pair RJ45 CAT5 cable. A custom cable
should not be used with the 090-50315-01 I/O card.
Table 1-2. UTI Connector Pin Assignments
Pin Signal
Comment
1DTI+ DTI
2DTI DTI
3 No connection
4 No connection
5 No connection
6 No connection
7 No connection
8 No connection
Table 1-3. Custom Cable RJ-45 Wiring Connections: UTI Port to Expansion Shelf EXP Port
UTI Port on I/O Card
Mating Connector
Pins
Signal
EXP Port on Expansion Shelf
Mating Connector
Pins
1DTI+ 7
2DTI 8
