098-00028-000 Revision F – May, 2012 TimeProvider 5000 Users Guide 35
Chapter 1 Overview
TimeProvider 5000 Connections
Communications Connections
The IMC allows user control of the TimeProvider 5000 through either the Ethernet
Management port or the EIA-232 serial port.
Ethernet Management Port
The Ethernet Management port on the IMC is standard 10/100Base-T shielded
RJ-45 receptacle. To connect the TimeProvider 5000 to an Ethernet network, use a
standard twisted-pair Ethernet RJ-45 cable (CAT5 minimum).
Expansion Management Port
The expansion Management port on the IMC is a standard 10/100Base-T shielded
RJ-45 receptacle. To connect the TimeProvider 5000 to a TP E10 or TPE30
expansion shelf, use a standard twisted-pair Ethernet RJ-45 cable (CAT5
minimum).
The connector pinouts for the expansion Management port, and all expansion ports,
are listed in Table 1-4.
Table 1-4. Expansion RJ-45 Connector Pin Assignments
Pin Signal
Comment
1RX+
(Receive positive)
Ethernet (10/100Base-T)
2RX
(Receive negative)
Ethernet (10/100Base-T)
3TX+
(Transmit positive)
Ethernet (10/100Base-T)
4 Reserved
5 Reserved
6TX
(Transmit negative)
Ethernet (10/100Base-T)
7DTI+DTI
8DTI DTI
