126 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 3
TimeProvider 5000 CLI Command Set
Port dti link dti status eth link
----------------------------------------------------------
in1: up active up
in2: disabled standby down
out1: up active up
out2: down disconnected up
Response 3b:
Port dti link dti status eth link
--------------------------------------------------------
in1: down disqualified down
in2: up disqualified up
out1: up active up
out2: down disconnected up
Level : DTI input port status of “active” means the port is
selected as reference
Level : User, Config and Admin
Table 3-1. Expansion Port Status
Status Input/Output Description
Active Input and Output An input is qualified and also selected.
An output that is determined to be "active", "standby", or
"redundant" by the downstream input.
Standby Input only An input is qualified but not selected.
If the active input is disqualified, the standby input will be
selected after several seconds.
Redundant Input only An input that could have been qualified, except that a
timing loop condition existed.
If the other input is disqualified, the redundant input will
be selected after a delay to allow stabilization of the
system.
Disqualified Input only An input that is disqualified
Disconnected Output only A DTI output that is not connected to a DTI input
