330 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 4 Provisioning
Provisioning the Dedicated Outputs
Provisioning the Dedicated Outputs
Provisioning E1 Outputs
Port 3 and Port 4, the two dedicated output ports on the 090-50311-01 version of the
I/O module, must be provisioned for the type of output signal. The “set output
”
command is used to provision the dedicated E1 output characteristics. See Figure
4-24.
2048kHz Frame Type
To provision the dedicated output Port 3 for a frametype of 2048kHz, CRC disabled,
SSM disabled, and to enable the port:
1. Login at the Admin or Config-user level.
2. Type
set output frametype port3 freq2048khz and press Enter.
3. Type
set output crc port3 disable and press Enter.
4. Type
set output ssm port3 disable and press Enter.
5. Type
set output state port3 enable and press Enter.
CCS Frame Type
To provision output Port 4 with a frametype of CCS, CRC enabled, SSM enabled,
SSM-bit of 6, and to enable the port:
1. Login at the Admin or Config-user level.
2. Type
set output frametype port4 ccs and press Enter.
3. Type
set output crc port4 enable and press Enter.
4. Type
set output ssm port4 enable and press Enter.
5. Type
set output ssm-bit port4 6 and press Enter.
Note: Units that provide dedicated E1 outputs must be ordered
from the factory; they cannot be reconfigured in the field.
Note: SSM is only supported for the frametypes ESF, CAS with
CRC4 and CCS with CRC4. SSM should not be enabled for other
output frame types
