Provisioning the 1PPS+TOD Inputs
Provisioning the 1PPS+TOD Inputs
Ports 1 and 2 on the 090-50315-01 version of the I/O module are 1PPS+TOD
inputs.
Use the following procedure to set the priority value for these ports, set the cable
delay value, and to enable the inputs (Priority=5, cable delay=2500 ns in this
example).
1. Login at the Admin or Config-user level.
2. Type
set pps-tod priority port1 5 and press Enter.
3. Type
set pps-tod cable-delay port1 2500 and press Enter.
4. Type
set pps-tod state port1 enable and press Enter.
Note: Disabling the input port will clear all alarms and events related
to this port.
