Appendix B Specifications and Factory Defaults
Specifications
Serial Port
LAN Port
Input Signals
Table B-5. TimeProvider 5000 Main Shelf - Serial Port Specifications
Item Description
Connector Type 9-pin, female D connector
Connector Label Craft
Interface RS-232, data terminal equipment (DTE)
Baud Rate 57.6 Kbps
Data Bits 8
Parity Bit None
Stop Bits 1
Flow Control None
Table B-6. TimeProvider 5000 Main Shelf LAN Port Specifications
Connector Description
MGMT RJ-45 (10Base-T/100 Base-T) - Supports telnet
sessions
and SSH sessions over TCP/IP.
Table B-7. TimeProvider 5000 Main Shelf Input Signal Specifications
Parameter Specification
GPS
Requirement Total gain should be between 25 dB and 35 dB,
including gain of antenna and loss of cable
Antenna Power 5V, typical
Interface SMA connector, female
GNSS
Requirement Total gain should be between 25 dB and 35 dB,
including gain of antenna and loss of cable
