Appendix F PTP Probe Option
Controlling the Probe With TimeMonitor PDV
Functions of TimeMonitor PDV
TimeMonitor PDV has four basic functions:
1. Connect
2. Configure
3. Measure
4. Analyze
These functions are shown in Figure F-7 and described in Table F-3:
Command This field is used to manually enter CLI commands for the Probe.
TimeMonitor PDV must be in Command mode (see Item 1) to use this
feature. Click the Send button (see Item 25) to send the command to
the Probe.
Title Bar Shows the product name. The cursor has a pointer shape in this area.
Message If live data is being collected, then the Elapsed Time is shown.
Main Display Probe measurement data points are displayed in this section when the
Check button (see Item 2) is pressed, as well as any responses or
messages from the TP 5000 probe during a CLI session.
Table F-2. Descriptions of TimeMonitor PDV GUI  Main Screen (Continued)
Item Label Description
