Appendix B Specifications and Factory Defaults
Factory Defaults
Table B-40. TP E10 - Expansion Shelf PTP Parameters
Description Default Value Value Range
PTP Port x State Enable Enable | Disable
PTP Timescale Auto PTP | ARB | Auto
PTP Two-Step Clock Disable Enable | Disable
PTP Alternative Master Disable Enable | Disable
PTP Priority 1 128 0 to 255
PTP Priority 2 128 0 to 255
PTP Domain 0 0 to 255
PTP Dither Disable Enable | Disable
PTP Clock Identity MAC-based value
(i.e. FF:FE inserted in the middle of
MAC address)
64-bit value
PTP Multicast Sync Interval 0 7 to 7
PTP Multicast Announce Interval 1 4 to 4
PTP Multicast Delay Interval 7 7 to 7
PTP Multicast Announce Timeout 3 2 to 10
PTP Multicast Client Timeout 300 10 to 3600 sec
Table B-41. TP E10 - Output Port Parameters
Description Default Value Value range
SyncE Ethernet Synchronization
Messaging Channel (ESMC)
Disable Enable | Disable
Enabled SyncE/PTP ports 8 ports
(Port 1-8)
8 ports | 16 ports
Note: The second set of SyncE/PTP ports (Ports 9-16) for the TP E10
expansion shelf are available as a purchasable option.
