098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 41
Chapter 1 Overview
TimeProvider 5000 Connections
1PPS+TOD Input Connections
Two of the RJ-45 ports (1PPS+TOD-1 and 1PPS+TOD-2) on the 090-50315-01
expansion version of the I/O module (Figure 1-6) are input ports for 1PPS and TOD
information transmitted at RS-422 level. See Table 1-7 for pin-outs for the
1PPS+TOD connectors.
GNSS Connection
The IMC (versions 090-50331-04 and 090-50331-05) has an SMA connector for
input from GPS (090-50331-05) and Beidou/GPS (090-50331-04) navigation
satellites to provide a frequency and time reference (see Figure 1-3). This port
supports input from both GPS and Beidou satellites for the 090-50331-04 version of
the IMC and input from GPS satellites for the 090-50331-05 version.
GPS Connection
The IMC (versions 090-50331-01, 090-50331-02, 090-50331-04, and
090-50331-05) has an SMA connector for GPS input to provide a frequency and
time reference (see Figure 1-3).
Table 1-7. 1PPS+TOD Port Pin-Outs - RJ45 Connector
Pin Signal Comment
1 No Connection Default state is open (high impedance)
2 No Connection Default state is open (high impedance)
3 422_1_N 1PPS
4 GND RS422 GND
5 GND RS422 GND
6 422_1_P 1PPS
7 422_2_N TOD time information
8 422_2_P TOD time information
