294 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 4 Provisioning
Provisioning PTP
Table 4-7. Hybrid (Multicast-Hybrid) Proprietary Profile
Attribute Default for TP 5000 Range for TP 5000
clockClass Not defined 6, 7, 13, 14, 52, 58, 248
Announce Interval -3 -4 to +4
Sync Interval -7 -7 to +7
Domain 4 0 to 255
Table 4-8. Option 1 - SSM Mapping to QL and clockClass per G.781 and G.8265-1
Option 1 SSM (hex) Clock QL PTP clockClass PQL
04FF QL-PRC 84 1
08FF STU 82 2
0CFF QL-SSU-A 90 3
0CFF Type I 90 4
78FF QL-SSU-B 96 6
10FF QL-SEC/EEC1 104 7
30FF QL-DNU 110 9
Others (or absent) Invalid n/a 15
Table 4-9. Option 2 - SSM Mapping to QL and clockClass per G.781 and G.8265-1
Option 2 SSM (hex) Clock QL PTP clockClass PQL
04FF QL-PRS 80 1
08FF QL-STU 82 2
0CFF QL-ST2 86 3
0CFF Type I 86 4
78FF QL-TNC 90 5
7CFF QL-ST3E 100 6
10FF QL-ST3E/EEC2 102 7
