58 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Chapter 2 Installing
Getting Started
Getting Started
Before you begin to install the TimeProvider 5000, TimeProvider E10 or
TimeProvider E30, review the information in this section.
If you encounter any difficulties during the installation process, contact
Symmetricom Global Services (SGS). See Contacting Technical Support, on page
405 for telephone numbers. Contact SGS - Product Technical Support for technical
information. Contact Customer Service for information about your order, RMAs, and
other information.
Security Considerations for TP5000 Installation
The TP 5000, TP E10 and TP E30 should be installed in a physically secure
location.
The TP 5000's IMC Module's Ethernet port should be installed behind the
company's firewall to prevent public access.
Whenever possible, the TP 5000's Ethernet service ports should be installed
behind the company's firewall to prevent public access.
Site Survey
Before you begin installation, determine the chassis location, ensure the
appropriate power source is available (–48 VDC), and ensure that the equipment
rack is properly grounded.
The TimeProvider 5000 is designed to mount in a 19-inch (48 cm) rack, occupies
1.75 in (4.5 cm, 1 RU) of vertical rack space, and has a depth of 18 in (45.7 cm).
The TimeProvider E10 and TimeProvider E30 expansion shelves are also designed
to mount in a 19-inch (48 cm) rack, and each occupies 1.75 in (4.5 cm, 1 RU) of
vertical rack space, and has a depth of 10 in (25.4 cm). .
The TimeProvider 5000 is to be installed into a rack with permanent connection to
the -48VDC mains. This connection is to be made to a branch over-current,
short-circuit protection device with replaceable fusing of 5 amps, maximum. For
permanently connected equipment a readily accessible disconnect device shall be
incorporated in the building installation wiring.
Note: 1RU above the TimeProvider 5000 must be left
unoccupied for heat dissipation
Note: 23-inch (58.42 cm) rack mounting adapters are also available
as a separately ordered item. 21-inch (ETSI) rack mounting adapters
are available as a separately ordered item.
