098-00028-000 Revision F – May, 2012 TimeProvider 5000 Users Guide 441
Appendix B Specifications and Factory Defaults
Specifications
TP E10 Expansion Shelf Output Signal Specifications
Table B-12. TP E10 Expansion Shelf Output Signal Specifications
Parameter Specification
PTP
Ports Ethernet Small Form-factor Pluggable (SFP)
Optical 1000 Base-X
Electrical 100/1000 Base-T
Accuracy
System tracking GPS or
Beidou GNSS
System tracking 1PPS+TOD
input
The difference between the PTP outputs
and UTC time 200 ns
The difference between the PTP outputs
and input time < 50 ns
SyncE
Ports Ethernet Small Form-factor Pluggable (SFP)
Optical 1000 Base-X
(
SyncE is only accessible on Ports 1-16
with optical SFP)
1PPS
Impedance 50 unbalanced
Amplitude 2.0 Vpp
Signal type Square Wave
Rise Time < 20 ns
Connector SMB, male
Pulse Width 5 s ±10%
Long-term Frequency Stability <0.01 ppb, when locked to PRC/GPS
1PPS Output Stability
System tracking GPS or
Beidou GNSS
System tracking 1PPS+TOD
input
MTIE and TDEV meet the specifications
defined in ITU-T G.811, with observation
time of 10,000 seconds.
MTIE and TDEV meet the specifications
defined for Type I clock in ITU-T G.812, with
observation time of 10,000 seconds.
Phase Error <100 ns, when locked to GPS
