098-00028-000 Revision F – May, 2012 TimeProvider 5000 Users Guide 43
Chapter 1 Overview
Physical Description
Physical Description
The TimeProvider 5000 consists of a 19-inch (48 cm) rack mount chassis, plug-in
modules, and hardware. The TP E10 and TP E30 each consist of a 19-inch (48 cm)
rack mount chassis and hardware.
The TimeProvider 5000 has one I/O module slot, two IOC module slots, and one
IMC module slot. The grounding lug is located near the I/O module and the power
supply connectors are located on both sides of the chassis (see Figure 1-11). The
minimum configuration is an I/O module, an IOC module, and an IMC module. The
second IOC module slot is available for redundancy. See TimeProvider 5000 Part
Numbers, on page 398.
The TimeProvider E10 SyncE/PTP expansion shelf has one block of RJ-45
expansion connectors (2 Input ports, 2 Output ports), two blocks of Gigabit SFP
connectors (16 ports). The shelf also has six LEDs located on the left side of the
front panel. The shelf features a recessed rotary switch with 10 positions that is
used to set the shelf ID and a recessed reset switch. The grounding lug is located
on the right side of the front panel. The power supply connectors are located on
both sides of the chassis (see Figure 1-12).
The TimeProvider E30 E1/1PPS+TOD expansion shelf has one block of RJ-45
expansion Input/Output connectors (2 Input ports, 2 Output ports), two blocks of
SMB output connectors (12 ports), and three blocks of RJ-45 output connectors (12
ports). The shelf also has six LEDs located on the left side of the front panel. The
grounding lug is located on the right side of the front panel. The power supply
connectors are located on both sides of the chassis (see Figure 1-13).
Note: The TP 5000, TP E10, and TP E30 comes equipped with
19-inch rack mounting brackets. 23-inch (58.42 cm) rack mounting
adapters are also available as a separately ordered item. 21-inch
(ETSI) rack mounting adapters are available as a separately ordered
item.
