382 TimeProvider 5000 Users Guide 098-00028-000 Revision F – May, 2012
Chapter 6 Maintenance and Troubleshooting
Troubleshooting
Diagnosing the Expansion Shelf Reading LED Conditions
Table 6-5 shows the function of the LED indicators on the front panel of an
expansion shelf.
GPS Status
GPS engine
status indicator
GPS Green - ToD source is GPS and
GPS engine/interface is
operating normally
n/a
Amber - ToD source is GPS and
GPS engine or antenna
is not tracking satellite
Use “show alarm” command to
view alarm IDs and descriptions.
See
Table A-1 in Appendix A,
System Messages
for corrective
actions.
Use “show GPS” command to see
detected satellites and their signal
levels.
Off - ToD source is not GPS This LED should only be OFF if
the TP5000 is not using GPS.
Ethernet
Management
Port
LEDs on the
Ethernet
connector
MGMT Left Amber Flash - Activity n/a
Left Off - No Activity n/a
Right Green - Link has been
established
n/a
Right Off - Link has not been
established
Check cable and connections
Table 6-5. LED Conditions for the Expansion Shelf
Indicator Label Description Corrective Action
Power
Indicator
PWR Green - Shelf power available n/a
Off - Shelf power not available Check power supply
See
Table 6-2 ,“No LED lit on
any module” for probable causes
and more corrective actions.
Table 6-4. LED Conditions for the IMC (Continued)
Indicator Label Description Corrective Action
