512 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Appendix F PTP Probe Option
Provisioning the Probe
Return Port to Grandmaster Mode
The packet- service for a port must be set to ptp-gm or ntp-server to change that TP
5000 IOC port out of PTP probe mode. See Table F-5.
Set the IP Address for Probe MGMT Port
The TP 5000 probe can be controlled through the Craft port or through the MGMT
port of the IMC module. The MGMT port may be more effective for gathering data
with the Probe because it can support higher data rates than the Craft port. The
Craft port can only support SYNC Interval settings of 0.5 seconds (2 Hz) or slower.
The IP address for the MGMT port can only be set with CLI commands. It may be
necessary to connect to the TP 5000 via the Craft port to set the IP address.
Table F-5. Return to Grandmaster Mode Procedure
TimeMonitor PDV CLI Command
1. Click on the Command radio button to put
TimeMonitor PDV into the proper mode for
making Probe changes.
2. Click the Login button to login to the Probe.
The Probe will prompt for Username and
Password.
3. Select the desired Probe port using the radio
buttons (see Item 2).
4. Click on the Probe Disable button.
Use the command:
set packet-service ioc1-1 {ptp-gm
| ntp-server | ptp-probe}
Example
:
To return port 1 of IOC1 to PTP grandmaster
mode:
1. Login at the Admin or Config-user level.
2. Type set packet-service ioc1-1
ptp-gm and press Enter.
