Chapter 4 Provisioning
Provisioning the Programmable E1/T1 Inputs
 If input SSM for a port has a worse quality level than the IOC oscillator - Type II
for Rb IOC and Type 1 for Quartz IOC -the input port will be disqualified
 If SSM is enabled for an input port and the signal does not support SSM or is not
sending a valid SSM, then the input will be disqualified. The SSM-value for the
input will be set to 15 (invalid). If there is not another qualified reference to switch
to, the system will go to holdover.
 If any of the following conditions are detected at an input port, that input signal
will be disqualified: Loss of signal (LOS), Out-of-framing (OOF), or Alarm
indication signal (AIS)
Table 4-16 illustrates some example situations. The Output PQL values shown
assume that no other references are available
Table 4-16. Input Frametypes: SSM-States and SSM-values
PQL-Value
The “PQL value” parameter that is used with the “set input” command corresponds
to the Priority Quality Level (PQL) values for reference input signal types, as shown
in Table 4-17. The PQL is a representation of traceability for the signal presented at
the input ports, where a PQL value of 15 represents an invalid SSM. If SSM is
disabled for an input port, then the TP5000 will use the user-assigned PQL value for
that input port.
Selected
Input
Signal
SSM State
Current
PQL value
Disqualify Signal
Based on SSM?
Output
PQL value
1544kHz Disable User-value Allow User-value
Enable 15 Disqualify OSC (holdover)
D4 Disable User-value Allow User-value
Enable 15 Disqualify OSC (holdover)
ESF Disable User-value Allow User-value
Enable with valid SSM Input SSM Allow Input SSM
with no SSM 15 Disqualify OSC (holdover)
with unsupported
SSM code
15 Disqualify OSC (holdover)
with STU code 2 (STU) Allow 2 (STU)
with DUS code 9 (DUS) Disqualify OSC (holdover)
Note: SSM during bridging will be the last SSM value of input
reference while clock was in normal lock state.
