52 TimeProvider 5000 Users Guide 098-00028-000 Revision F – May, 2012
Chapter 1 Overview
Functional Description
Communication Ports
Communications ports on the IMC allow you to provision, monitor, and troubleshoot
the chassis. You can communicate with the TimeProvider 5000 using either CLI or
SNMP protocols.
Local Craft Serial Port
The EIA-232 port supports local control; you can configure the TimeProvider 5000
with CLI commands using a terminal or computer with terminal emulation software.
The connector is located on the IMC module. The Local port is configured as a DCE
interface and the default settings are as follows:
Baud = 57.6K
Data Bits = 8 bits
Parity = 0
Stop bits = 1
Flow Control, None
Management Ethernet Port
The Management Ethernet connector provides connectivity to an Ethernet local
area network. Each Ethernet port has a unique internet protocol (IP) address and
once the IP address is set and a connection is made to a LAN, you can access the
TimeProvider 5000.
Synchronization and Timing Inputs
The TimeProvider 5000 can use either GPS, Beidou, E1, T1, or 1PPS+TOD signals
as external input references. The GPS and GPS/Beidou references connect to SMA
connectors on the IMC card. The GPS/Beidou port is labeled "GNSS". The E1 and
T1 inputs are configurable ports located on the I/O module. The 1PPS+TOD input
ports are located on the 090-50315-01 version of the I/O module.
Synchronization and Timing Outputs
The TimeProvider 5000 has four GbE timing outputs (2 per IOC card), which can be
configured as either Precision Timing Protocol (PTP) or Network Timing Protocol
(NTP) outputs. The expansion version of the I/O card, 090-50315-01, also features
two DTI timing outputs that are used to provide timing to expansion shelves.
Note: The SNMP feature can either be ordered in a new system, or
added to a previously ordered system as a field upgrade (see Table
6-7 for part number). Contact your Symmetricom representative for
more information.
