Symmetricom TimeProvider 5000 User Manual

098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 317
Chapter 4 Provisioning
Provisioning the Input Reference
Setting an E1/T1 Input as Reference
An E1 or T1 input can be configured as a frequency reference. For details about
configuring the E1 or T1 input parameters, see Provisioning the Programmable
E1/T1 Inputs, on page 318.
Example
To provision I/O ports 1 and 2 as inputs and use either as the reference, perform the
following steps:
1. Login at the Admin or Config-user level (see Logging In, on page 275).
2. Type
set ref mode frequency and press Enter.
3. Type
set ref criteria priority and press Enter.
4. Type
set io port1 input and press Enter.
5. Type
set io port2 input and press Enter.
6. Type
set input state port1 enable and press Enter.
7. Type
set input state port2 enable and press Enter.
8. Type
show ref and press Enter to verify that the reference mode has been set
to Frequency..
Note: Command “set ref mode time” has the same meaning as
“set tod-source GPS” and the command “set ref mode
frequency” has the same meaning as “set tod-source sys”.
The
set tod-source command has been deprecated.
Note: The reference criteria MANUAL is no longer supported. Only
PRIORITY and SSM are supported for reference selection.
Manual selection of a reference input can be done by disabling all
reference input ports except the desired one.
The “set ref override” command is no longer supported.
Note: Disabling the input port will clear all alarms and events related
to this port.
