098-00028-000 Revision F – May, 2012 TimeProvider 5000 User’s Guide 227
Chapter 3
TimeProvider 5000 CLI Command Set
set ptp-probe
Use this command with a TP 5000 that is configured in Probe mode to specify the
Grandmaster IP address and Clock ID. This command is used to set the PTP
profile, interval rate for Sync and Delay Requests and the lease duration for the
specified Probe IOC card and port. This command is also used to restart the
specified Probe IOC card and port.
The PTP probe mode supports three profiles:
Default: Multicast Layer 3 of 7-layer model
Ethernet-Default: Multicast Layer 2 of 7-layer model
Telecom-2008: Unicast.
Command Syntax:
To set the IP address and Clock ID for the Grandmaster being tested by the
Probe:
set ptp-probe ioc1-[y] active-probe gm-clock-id <clock-id>
gm-ip <addr> [vlan-id <vlan>]
where
y = 1|2, the port number on the IOC
<clock-id> is in the form “xx:xx:xx:xx:xx:xx:xx:xx”
To set the PTP profile for the Probe:
set ptp-probe ioc1-[y] active-probe profile {default |
telecom-2008 | Ethernet-default}
where
y = 1|2, the port number on the IOC
<clock-id> is in the form “xx:xx:xx:xx:xx:xx:xx:xx”
To set the interval rate for Sync and Delay Requests from the Probe:
set ptp-probe ioc1-y active-probe interval <int-value>
The interval is 2
z
seconds, where z is <int-value>.
To set the maximum lease duration for the Probe:
Note: The PTP probe option must be purchased to enable the
functionality of all “ptp-probe” commands.
Note: PTP probe is not supported through SNMP..
