428 TimeProvider 5000 User’s Guide 098-00028-000 Revision F – May, 2012
Appendix A System Messages
System Notification Messages
* Index is a code used for trouble shooting at Symmetricom facility.
91 DTI input port active
0  1 0=Port 1, 1=Port 2
92 EXP connected
0  9 index is expansion shelf ID
number
93 EXP disconnected
0  9 index is expansion shelf ID
number
94 EXP ID changed
0  9 index is expansion shelf ID
number
95 EXP interface link down
0  3 0=ETH1, 1=ETH2
2=ETH3, 3=ETH4
96 EXP has duplicated shelf ID
???? index is shelf ID
97 IMC-EXP software incompatible
0  9 index is expansion shelf ID
number
98 GNSS mode changed
0  1 0= to GPS, 1= to Beidou
99 Fan failure
0  3 0=fan 1, 1=fan 2
2=fan 3, 3=fan 4
100 Multiple fans failure
n/a n/a
101 PPS-TOD input communication
error
0  1 0= PPS_TOD-1
1 = PPS_TOD-2
102 PPS-TOD input unusable
0  1 0= PPS_TOD-1
1 = PPS_TOD-2
103 Time and phase questionable
n/a n/a
104 NTP server near packet limit
0  1 0=ETH1, 1=ETH2
Table A-2. Secondary Index Descriptions for System Notification Messages
Event
ID
Description
Secondary
Index
Secondary Index
Description
