I-16 65K510DEP08-1A
alarmaidexternal‐input8 8
alarmaidexternal‐input9 9
alarmaidexternal‐input10 10
alarmaidexternal‐input11 11
alarmaidexternal‐input12 12
alarmaidexternal‐input13 13
alarmaidexternal‐input14 14
alarmaidexternal‐input15 15
alarmaidexternal‐input16 16
alarmaidpower‐failac 19
alarmaidpower‐faildca 17
alarmaidpower‐faildcb 18
alarmcondition‐codeexternal‐input1 ʺEXT‐IN‐1ʺ
alarmcondition‐codeexternal‐input2 ʺEXT‐IN‐2ʺ
alarmcondition‐codeexternal‐input3 ʺEXT‐IN‐3ʺ
alarmcondition‐codeexternal‐input4 ʺEXT‐IN‐4ʺ
alarmcondition‐codeexternal‐input5 ʺEXT‐IN‐5ʺ
alarmcondition‐codeexternal‐input6 ʺEXT‐IN‐6ʺ
alarmcondition‐codeexternal‐input7 ʺEXT‐IN‐7ʺ
alarmcondition‐codeexternal‐input8 ʺEXT‐IN‐8ʺ
alarmcondition‐codeexternal‐input9 ʺEXT‐IN‐9ʺ
alarmcondition‐codeexternal‐input10 ʺEXT‐IN‐10ʺ
alarmcondition‐codeexternal‐input11 ʺEXT‐IN‐11ʺ
alarmcondition‐codeexternal‐input12 ʺEXT‐IN‐12ʺ
alarmcondition‐codeexternal‐input13 ʺEXT‐IN‐13ʺ
alarmcondition‐codeexternal‐input14 ʺEXT‐IN‐14ʺ
alarmcondition‐codeexternal‐input15 ʺEXT‐IN‐15ʺ
alarmcondition‐codeexternal‐input16 ʺEXT‐IN‐16ʺ
alarmcondition‐codepower‐failac ʺPOWERʺ
alarmcondition‐codepower‐faildca ʺPWRA‐1ʺ
alarmcondition‐codepower‐faildcb ʺPWRB‐1ʺ
alarmdescriptionexternal‐input1 ʺExtAlmInput1ʺ
Table I-26. System Alarm Defaults (Continued)
Provisioning Option Default Setting

ADTRAN Total Access 5000 Specifications

Interfaces

craft interface	DB-9 RS-232 Electrical Interface (Async)
admin interface	DB-9 RS-232 DTE Electrical Interface (Async with Modem Control Signals)
network management port	DB-9 RS-232 DTE Electrical Interface (Async)
ethernet interface	10Bt
external alarm inputs	16

Operating Environment

operating temperature	-40°C to +65°C
storage temperature	-40°C to +70°C
relative humidity	Up to 95%, non-condensing

Weight and Dimensions

height	9.25 in.
width	0.08 in.
depth	9.5 in.
weight	0.6 lbs.
