R3765/67G Series Network Analyzer Operation Manual

5.3 Narrow Band/Wide Band Sweep Measurement

5-26

Display two channels simultaneously.

[DISPLAY] {DUAL CH ON/OFF}

The measurement screen is as follows.

Figure 5-23 Two Channels Simultaneous Display (Overlap Display)
