R3765/67G Series Network Analyzer Operation Manual
7.11 INSTRUMENT STATE Block
7-127
7.11 INSTRUMENT STATE Block
The INSTRUMENT STATE block is used to set the system control functions which have no concern
with the measurement. The functions are provided such as a time/date set, limit-line test, save/
recall, and hard copy.
[SAVE] : Calls the save menu to save such as a setting data and calibration data
of the R3765/67G series. (Refer to sub-section 7.14.1.)
[RECALL] : Calls the recall menu to recall such as a setting data and calibration
data of the R3765/67G series. (Refer to sub-section 7.14.8.)
[COPY] : Calls the copy menu to execute the hard copy of screen for a plotter/
printer. (Refer to section 7.15.)
[SYSTEM] : Calls the system menu to set such as an internal disk, date/time display
and limit line. (Refer to sub-section 7.11.1.)
[PRESET] : Initializes the settings of the R3765/67G series. (Refer to section 4.4.)
INSTRUMENT STATE
SAVE RECALL COPY SYSTEM PRESET
