3.5 Measurement Samples of Simple Transmission Characteristics
3-9
3.5 Measurement Samples of Simple Transmission Characteristics
3.5.1 Setup and Setting
The setup of the R3765/67G series is performed as shown in Figure 3-7 or Figure 3-8 according
to the type.
Note: R3765/67G SERIES cannot be connected to R396X SERIES S parameter test set.
(1) AG type
Figure 3-7 The Setup of Transmission Characteristic Measurement (AG Type)
(2) BG/CG type
Figure 3-8 The Setup of Transmission Characteristic Measurement (BG/CG Type)
B PORTSOURCE
DUT
A PORT
R3765AG/67AG
TEST PORT 2TEST PORT 1
DUT
R3765BG/67BG/65CG/67CG
