R3765/67G Series Network Analyzer Operation Manual
3.5 Measurement Samples of Simple Transmission Characteristics
3-10
• DUT to use for the measurement sample is the band-pass filter of center frequency 880MHz.
• All the screen displays used here are display samples of R3767CG.
The displayed contents of input port in the upper left portion of the screen are different depending
on the model.
The display of each type is as follows. (Active channel: CH2).
TRN : TRANSMISSION
(3) Setting
Press [PRESET] to preset.
Set the R3765/67G series as follows.
Note: OPT11 or OPT14 uses a different [MEAS] menu.
For more information, refer to the description on page 7-10.
AG type BG type CG type
B/R TRN S21
Block name Setting Key operation
ACTIVE
CHANNEL
Set the channel to 2. [CH 2]
RESPONSE Select the input port in the
receiver part.
Set the measurement
format to magnitude (log
display).
AG type :
[MEAS] {B/R} (Initial setup)
BG type :
[MEAS] {TRANSMISSION} (Initial setup)
CG type :
[MEAS] {S21 TRANS FWD} (Initial setup)
[FORMAT] {LOG MAG} (Initial setup)
STIMULUS Center frequency 880MHz
Span frequency 100MHz
[CENTER] [8] [8] [0] [MHz]
[SPAN] [1] [0] [0] [MHz]
1
2
