R3765/67G Series Network Analyzer Operation Manual
7.15 Hard Copy
7-158
7.15.6 Bitmap File Setup
Setting a bitmap file.
Operation procedure
Press [COPY] to call the copy menu.
Press {BITMAP FILE} to call the bitmap file menu.
Bitmap file menu
{SAVE TO DISK} : Saves bitmap files to the disk.
{COMPRESSION ON/OFF}
: Toggles the bitmap file compression ON or OFF.
{TRUNCATE ON/OFF}
: When there is more than one file with the same name, this
determines whether the older file is overwritten or saved
with a different name.
File name: printxxx.bmp
(<xxx> is a three-digit integer)
<xxx> is set to 000 at power-up time, then incremented
each time the data is saved.
When TRUNCATE is turned OFF, a file with the same
name as another file is saved with a different name after
the counter has been updated.
1
2
3
