R3765/67G Series Network Analyzer Operation Manual
7.11 INSTRUMENT STATE Block
7-128
7.11.1 System Menu
The Setting and the Explanation
Press the [SYSTEM] to call the system menu. (Refer to section A.4.)
System menu
{SYSTEM DRIVE} : Calls the system for selecting a drive to be used and
format type of the disk. (See step .)
{SET CLOCK} : Calls the real-time clock menu for setting a date/time.
(See step .)
{LIMIT MENU} : Calls the limit menu. (Refer to sub-section 7.12.1)
{SYSTEM CONFIG} : Calls the system configuration menu (refer to Section
7.11.2).
{SERVICE MENU} : Calls the service menu.
System drive menu
{DEFAULT DRIVE} : Calls the default drive menu.(See step .)
A drive selected on this menu is set as a current drive
when power is turned on.
{FORMAT TYPE} : Calls the disk format menu for selecting an initialize
format type. (See step .)
Default drive menu
{A:} : Selects the drive A.
Floppy disk drive (720kB, 1.2MB, 1.44MB) (*1)
{B:} : Selects the drive B.
RAM disk drive (2MB, without backup) (*2)
{C:} : Selects the C drive.
Compact flash disk drive (with backup). (*3)
The standard capacity is 8 MB. When OPT11 is
installed, the capacity is 32 MB.
{D:} : Selects the D drive.
Compact flash disk drive (with backup). (*3)
(*1) Floppy disks used for this instrument are formatted as FAT16
using MS-DOS Ver. 3.0. In addition, the built-in disk drive is com-
patible to three formats, however, the instrument can format floppy
disks with 720 KB (2DD) and 1.44 MB (2HD) only. (See step .)
(*2) Part of the built-in memory (DRAM) is allocated to the disk drive.
When the power supply is turned off once, all of the created files
are deleted. Therefore, the B drive should be restricted to the use
of temporary files when used to create the BASIC program.
(*3) The instrument is equipped with a compact flash disk used as a
memory device.
This disk is divided into multiple partitions, which are used depend-
1
2
3
6
3
4
5
4
5
