R3765/67G Series Network Analyzer Operation Manual
2.3 Screen Display Descriptions
2-14
Table 2-7 Screen Display Descriptions
No. Name Description
Real time clock Displays the year, month, day, day of the week and time.
Channel Displays a channel number.
Measured parameter Displays the measured parameter.
Format Displays data format (format data).
Scale reference Displays a reference value of display coordinate.
The reference position is displayed by using ’mark.
Scale/DIV Displays one scale value of display coordinate.
Load menu Displays files in this area when loading program from the disk
drive.
Active marker Displays an active marker value.
Marker list Displays a marker list.
Soft key menu Displays a soft key menu.
Active area Displays items selected by panel keys or soft keys and those
input values.
Status area Displays status which shows an operating state of the R3765/
67H series.
Trace display area Displays measurement data.
Label window Displays character lists used for a label and a register name.
Start/Center Displays the start/center of signal source.
Power/CW Displays the power/CW of signal source.
Stop/Span Displays the stop/span of signal source.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
