R3765/67G Series Network Analyzer Operation Manual
A.1 The Relation of Data between each Function
A-1
APPENDIX
Information for reference useful in operating is described in the APPENDIX.
A.1 The Relation of Data between each Function
Describes about the relation of data between each function.
A.1.1 The Relation of Data between each Channel and each Function
Describes about the relation between the data of each function and each channel.
The sub-channel of channel 1 is channel 3, and the sub-channel of channel 2 is channel 4.
(1) In the case of COUPLE CH ON
Function
Channel
CH1 CH3 CH2 CH4
MEAS
SUB MEAS
STIMULUS/RBW Common
Averaging
Smoothing
Common
Common
Common
Common
Trace operation
Parameter conversion
FORMAT
Scale
Marker
Limit line
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Independent
Mark shows that it can be set.
Mark shows that it cannot be set.
