R3765/67G Series Network Analyzer Operation Manual
3.5 Measurement Samples of Simple Transmission Characteristics
3-15
3.5.4 Phase measurement
Setup (refer to sub-section 3.5.1) and preset (refer to sub-section 4.4.1).
Set the R3765/67G series as follows.
The measurement here is performed with the span lessened and inside of the
bandwidth extended.
Calibrate (Normalize) frequency characteristics. (The same operation as sub-section
3.5.2.)
Note: OPT11 or OPT14 uses a different [MEAS] menu.
For more information, refer to the description on page 7-10.
Block name Setting Key operation
ACTIVE
CHANNEL
Set the channel to 2. [CH 2]
RESPONSE Select the input port in the
receiver part.
Set the measurement
format to phase display.
AG type :
[MEAS] {B/R} (Initial setup)
BG type :
[MEAS] {TRANSMISSION} (Initial setup)
CG type :
[MEAS] {S21 TRANS FWD} (Initial setup)
[FORMAT] {PHASE}
STIMULUS Center frequency 880MHz
Span frequency 50MHz
[CENTER] [8] [8] [0] [MHz]
[SPAN] [5] [0] [MHz]
1
2
3
To Next Page
