7.6 Marker Function
7-72
7.6.6 Marker Menu during Impedance Measurement
To read the impedance directly by the marker during parameter conversion or impedance mea-
surement, the marker menu can be selected from three modes (parameter conversion, Smith
chart display, or polar display).
The Setting and the Explanation
Press the [MKR] to call the marker menu. (Refer to section A.4.)
Press the {MARKER MODE MENU} to call the marker mode menu.
Marker mode menu
{CONVERSION MKR MENU [ ]} :
Calls the conversion marker menu which sets the marker data
display mode during the parameter conversion. (See step .)
{SMITH MKR MENU [ ]} :
Calls the Smith marker menu which sets the marker data
display mode during the Smith chart display. (See step
.)
{POLAR MKR MENU [ ]} :
Calls the menu which sets the marker data display mode
during the polar display. (See step .)
Conversion marker menu
{DEFAULT} : Displays the value corresponding to the data format.
{LIN MKR} : Displays the linear magnitude value and the phase
value.
When a format is selected except SMITH and POLAR in
the format menu, if SMOOTHING is set to ON, a correct
value cannot be obtained.
{Re/Im MKR} : Displays the complex data.
When a format is selected except SMITH and POLAR in
the format menu, if SMOOTHING is set to ON, a correct
value cannot be obtained.
Smith marker menu
{LIN MKR} : Displays the linear magnitude value and the phase
value.
{LOG MKR} : Displays the logarithmic magnitude value and the phase
value.
{Re/Im MKR} : Displays the complex data.
{R+jX MKR} : Displays the complex impedance.
{G+jB MKR} : Displays the complex admittance.
{Z0 VALUE} : Sets the characteristic impedance.
