7.6 Marker Function
7-71
• ACT MKR menu (2 of 2)
{COMPARE MARKER 6} : Changes the marker for comparison to the marker 6.
{COMPARE MARKER 7} : Changes the marker for comparison to the marker 7.
{COMPARE MARKER 8} : Changes the marker for comparison to the marker 8.
{COMPARE MARKER 9} : Changes the marker for comparison to the marker 9.
{COMPARE MARKER 10} : Changes the marker for comparison to the marker 10.
{ACTIVATE MARKER [ ]} : Calls the active marker menu. (Refer to sub-section
7.6.1.)
For FIXED MKR mode
Pressing the { REF=FIXED MKR} in step displays the difference between the
active MKR and the FIXED MKR ( ) on the active area of the screen.
To set the FIXED MKR position, press the {FIXED MKR POSITION} on the same
menu to call the FIXED MKR setting menu.
• FIXED MKR setting menu
{FIXED MKR STIMULUS}: Sets the FIXED MKR stimulus value.
{FIXED MKR VALUE} : For the Smith chart and polar display, sets the FIXED
MKR response value (real part).
{FIXED MKR AUX VALUE}: For the Smith chart and polar display, sets the FIXED
MKR response value (imaginary part).
{FIXED MKR ACTIVE MKR}:
Sets the FIXED MKR to the active marker position.
If changing the stimulus reference value or others cause the fixed marker to move
outside the screen, the fixed marker is not displayed.
The fixed marker can be displayed and set even if the delta mode is off.
If a parameter other than “1/S” has been set to CONVERSION ON in the parameter
conversion menu, the fixed marker can not be set nor displayed.
Note: FIXED MKR STIMULUS/VALUE/AUX VALUE can be set only with the ten-key.
