R3765/67G Series Network Analyzer Operation Manual
5.4 Multi-marker List Display
5-28
5.4 Multi-marker List Display
Here explains how to operate multi-marker.
• 880MHz band-pass filter is used as DUT.
Setup (filter connection) (refer to sub-section 3.5.1) and preset (refer to sub-section
4.4.1).
Press [CH 2] to set the active channel to 2.
Set the center frequency and the span.
[CENTER] [8] [8] [0] [MHz]
[SPAN] [2] [0] [0] [MHz]
Calibrate the frequency characteristic.
Remove DUT and connect the through adapter instead.
Normalize in this state.
Following [CAL] {NORMALIZE (THRU)}, return the connection to DUT (filter).
Display multi-marker.
Maximum 10 markers are displayed in one channel.
A marker is displayed in each calibration marking of the horizontal axis.
[MKR]
{ACTIVATE MARKER[ ]} {MARKER 2} []
{MARKER 3} [] []
{MARKER 4} [] [] []
{MARKER 5} [] [] [] []
{More 1/2} {MARKER 6} []
{MARKER 7} [] []
{MARKER 8} [] [] []
{MARKER 9} [] [] [] []
{MARKER 10} [] [] [] [] []
1
2
3
4
