R3765/67G Series Network Analyzer Operation Manual
7.13 GPIB Block
7-139
7.13.1 Controller Menu
The setting and the explanation
Press the [RUN] to call the controller menu. (Refer to section A.4.)
Controller menu
{RUN} : Starts a program.
{LOAD MENU} : Displays a file list and calls the load menu. (See step
.)
{LIST} : Displays a program list.
{CLS} : Clears the text display on the screen.
{CONT} : Restarts a program from the next line immediately after
program pauses.
{STOP} : Stops a program.
Load menu
{LOAD} : Loads the file specified by the cursor.
Following the completion of load, returns to the
controller menu. (See step .)
{CURSOR } : Shifts up the cursor used for specifying a file.
{CURSOR } : Shifts down the cursor used for specifying a file.
{DRIVE CHANGE} : Calls the drive menu to change the current drive. (See
step .)
Drive menu
{A:} : Selects the drive A.
Floppy disk drive
{B:} : Selects the drive B.
RAM disk drive (without backup)
{C:} : Selects the C drive.
A compact flash disk drive (with backup). (*3)
The standard capacity is 8 MB. When OPT11 is
installed, the capacity is 32 MB.
{D:} : Selects the D drive.
Compact flash disk drive (with backup) (*3)
(*1) Floppy disks used for this instrument are formatted as FAT16 using MS-DOS
Ver. 3.0. In addition, the built-in disk drive is compatible with three formats,
however, the instrument can only format floppy disks with 720 KB (2DD) and
1.44 MB (2HD). (See .)
(*2) Part of the built-in memory (DRAM) is allocated to the disk drive. When the
power supply is turned off, all created files are deleted. Therefore, the B drive
should be restricted to the use of temporary files when used to create BASIC
programs.
1
2
3
3
2
4
4
5
