9.2 Data Flow
9-2
9.2 Data Flow
The signal input into the receiver section is processed according to the following flow.
Figure 9-1 Data Flow
Input
Input port
mathematics
Error
correction
*Normalize
* Full port
calibration
AveragingFiltering
(Resolution,
bandwidth)
Raw data
Calibration
data
*Normalize
* Full port
calibration
Data Trace
mathematics
Electrical length
correction
Port Extension
Phase Offset
Memory
data
Unformatted
data
Format Smoothing
Format
data
Display
: Shows process. : Shows the data acquired as a result of the process.
Time domain
transformati
on
Note:
Gate
operation
Parameter
Conversion
