R3765/67G Series Network Analyzer Operation Manual
3.4 Basic Measuring Procedure
3-8
3.4 Basic Measuring Procedure
Shows basic measuring procedure of R3765/67G series.
Measuring procedure
Connection
Connect DUT (device under test) to the R3765/67G series.
Setting of the R3765/67G series
Initialize the R3765/67G series by pressing [PRESET] key.
Next, select the setting of the R3765/67G series according to the measurement to
perform.
(If necessary, connect DUT temporarily then.)
Calibration
Acquire the reference of magnitude and phase according to the measurement and
eliminate measurement error.
Measurement
Connect DUT and execute the measurement.
Read the parameter to measure by using marker function, etc.
Measured result output
The measured results can be output to the printer or the plotter with GPIB interface.
Also they can be saved in floppy disk.
