ADVANTEST R3765G Series User Manual

R3765/67G Series Network Analyzer Operation Manual
7.5 Calibration
7-36
7.5.5 Calibration Method
(1) Normalizing (transmission)
The Setting and the Explanation
Setup the R3765/67G series to the transmission measurement.
Connect a through standard between the measurement ports.
Press the [CAL] to call the calibration menu (1 of 2). (Refer to section A.4.)
Press the {NORMALIZE (THRU)}.
The message “Wait for Sweep .” is displayed and the calibration data are obtained.
The calibration is completed when the message disappears. (Note)
Connects a sample to perform the measurement.
(2) Normalizing (reflection)
The Setting and the Explanation
Setup the R3765/67G series to the reflection measurement.
Connect a open standard or a short standard to the measurement port.
Press the [CAL] to call the calibration menu (1 of 2). (Refer to section A.4.)
When the open standard is used, press the {NORMALIZE (THRU)}.
When the short standard is used, press the {NORMALIZE (SHORT)}.
The message “Wait for Sweep .” is displayed and the calibration data are obtained.
The calibration ends when the message disappears. (Note)
Connects a sample to perform the measurement.
Note: Do not move the R3765/67G series, the cable, the connector, the standard, and
the others during the message “Wait for Sweep .” is displayed.
When the set condition is changed during the message is displayed, the
message “Calibration aborted .” is displayed and the current calibration data
cannot be acquired.
1
2
3
4
5
1
2
3
4
5
