7.16 Communication with Peripheral Devices
7-168
7.16.2 RS-232 Interface
The R3765/67G series is equipped with an RS-232 interface as a standard. Therefore, data such
as measurement and analysis data can be output to an RS-232 printer.
The RS-232 interface defines mechanical and electrical characteristics of interface for connect-
ing between data terminal and data communication device standardized by Electronic Industries
Association (EIA).
Refer to “Regulation” for details.
(1) Connection connector and signal table
Connection connector : 29-pin D-sub connector (female type)
Signal table
(2) Printer output method
The LLIST or LPRINT command is used to output to the RS-232 printer by the R3765/67G
series. The setting such as a baud rate is defined by the CONTROL command.
Refer to “Programming manual” for details.
LLIST : Outputs BASIC program to the printer.
LPRINT : Outputs the contents of character strings, numeric values and variables.
CONTROL : Sets the values such as a baud rate, character length and others.
The setup value on power-up is as follows.
Baud rate : 9600 baud
Character length : 8-bit
Parity : None
Stop bit : 1-bit
Pin No. Signal name Description
1
2
3
4
5
6
7
8
9
CD
RxD
TxD
DTR
SG
DSR
RTS
CTS
RI
Carrier Detection
Receive Data
Transmit Data
Data Terminal Ready
Signal Ground
Data Set Ready
Request To Send
Clear To Send
Ring Indicators
