7.14 Save/Recall
7-141
7.14 Save/Recall
By using an internal disk, the R3765/67G series setting and the data saving/recalling (store/read)
can be performed.
The following two methods for saving data are provided in accordance with informations to be
saved and an internal disk.
• Save register : Saves the R3765/67G series setting and calibration data into compact flash
disk (Drive C).
• Store file : Store the R3765/67G series setting, calibration data and measurement data
on a floppy disk.
All informations ; Drive A (floppy disk)
7.14.1 Selection of Save Type
The setting and the explanation
Press the [SAVE] to call the save menu. (Refer to selection A.4.)
Save menu
{SAVE REGISTER} : Calls the save register menu. (Refer to sub-section
7.3.2.)
{CLEAR REGISTER} : Calls the clear register menu used for clearing the stored
save register. (Refer to sub-section 7.14.6.)
{STORE FILE} : Calls the store file menu used for storing files or setting
file names. (Refer to sub-section 7.14.3.)
The file list (Figure 7-18) will be displayed on the screen.
{PURGE FILE} : Calls the purge file menu used for clearing the stored
file. (Refer to sub-section 7.14.7.)
The file list (Figure 7-18) will be displayed on the screen.
{FORMAT DISK} : Initializes a floppy disk inserted in drive A.
Note: Before STORE FILE or PURGE FILE is executed, be sure to insert a formatted
floppy disk to the drive.
